square-flange-pool-pump-motors

<p>Replacement Single Speed 1HP; 1.25 SF - Up Rated, Threaded Shaft Motor.</p><p><strong>Used with: </strong>Sta-Rite Max-E-Glas, Max-E-Glas II, Dura-Glas, Dura-Glas II, Dyna-Glas, Dyna-Max Pentair Whisperflo, Pinnacle and Anthony AR2 Series.<br></p><p><strong>Key Features:</strong></p><ul><li><p>Sealed Ball Bearings</p></li><li><p>Capacitor Start</p></li><li><p>Open Dripproof</p></li><li><p>303 Stainless Steel Shaft</p></li><li><p>50°C Ambient</p></li><li><p>UL 1081 Design</p></li><li><p><strong>Note:&nbsp;NOT California Title 20 Compliant.&nbsp;</strong></p></li></ul>

<p>Century Full-Rated Two-Compartment 2 HP 2 Speed Pool Pump Motor, F/C-Type.<br></p><p><strong>Used with: </strong>Sta-Rite Dura-Glas, Max-e-Glas I &amp; II, Max-E-Pro<br></p><p><strong>Key Features:</strong></p><ul><li><p>Two Speed</p></li><li><p>All Copper Windings</p></li><li><p>Energy Efficient</p></li><li><p>50°C Ambient</p></li><li><p>Capacitor Start Low Speed</p></li><li><p>PSC High Speed</p></li><li><p>Open Dripproof</p></li><li><p>UL 1081 Design</p></li><li><p>303 Stainless Steel Shaft</p></li><li><p><strong>Note:&nbsp;NOT California Title 20 Compliant.&nbsp;</strong></p></li></ul>

<p>2-1/2 Horsepower, Up-Rate, Square Flange, Energy Efficient Motor. 230v</p>

<p>2 Horsepower, Up-Rate, Square Flange, Energy Efficient Motor. 208/230v. Used on Sta-rite Max-E-Glas II, Dura-Glas II, Max-E-Pro, Dyna-Glas, Dyna-Max </p><p></p><p><strong>Key Features:</strong></p><ul><li><p>Sealed Ball Bearings</p></li><li><p>Capacitor Start</p></li><li><p>Open Dripproof</p></li><li><p>303 Stainless Steel Shaft</p></li><li><p>50°C Ambient</p></li><li><p>UL 1081 Design</p></li><li><p>Energy Efficient</p></li><li><p><strong>Note:&nbsp;NOT California Title 20 Compliant.&nbsp;</strong></p></li></ul>

<p>Century(R) SQS1102R Square Flange 2-Speed Full-Rated Two-Compartment Pool Pump Motor; 1/0.17 HP, 3450/1725 RPM, 230 V, 48Y, Threaded Shaft</p><ul><li><p><strong>Note:&nbsp;NOT California Title 20 Compliant.&nbsp;</strong></p></li></ul>

<p><span>Century(R) Full-Rated Two-Compartment Pool Pump Motor, F/C-Type, Motor Design: Capacitor Start on Low Speed, PSC on High Speed, Open Dripproof Enclosure, 1.5/0.19 HP, 2.21 THP, 3450/1725 RPM, 48Y Frame, Voltage Rating: 230 V, 10.0/3.0 A, Frequency Rating: 60 Hz, 1-Phase, 2 -Speed, Mounting Type: C-Face, Motor Thermal Protection: Auto, Insulation Class: B, 1.47 Service Factor, Ball Bearing, Ambient Temperature: 50 deg C, CCWPE Shaft Rotation, Threaded Shaft, Shaft Diameter: 5/8 Inch, Overall Length: 13.67 Inch, 5-5/8 Inch Diameter, Continuous Duty, Square Flange, Shaft Material: 303 Stainless Steel, Satin Black</span></p>

<p>1-1/2 Horsepower, Square Flange, 2 Speed, Up Rate Motor. 230v</p>

<p>Square Flange FR .75HP 2SP 230V</p>

Square Flange UR 1HP 2SP 230V

<p>Energy Efficient Square Flange FR .75HP 2 Speed115V</p>

<p>The U.S. MOTORS TEQ225 is an AQUA-SHIELD PRO Pool/Spa Pump 48Y TEFC Square Flange Motor. It runs at 2.25THP and 115/208-230V. Square Flange Pump Motors are the most common motor frame used today. These frames attach directly to the pump.</p>
